Fuel Lines, Gasoline Vehicles for 2005 Mercedes-Benz S430
No.
Part # / Description / Price
Price
5
MSRP $135.00
$97.20
10
Binder
Mercedes-Benz
Mercedes-Benz Description: Fuel pump to fuel tank. 21.5-22.5 mm. Activated charcoal filter to fuel filler neck. 21.5-22.5 mm. Line to line. 21.5-22.5 MM.
MSRP $8.00
$5.90
MSRP $8.00
$5.90
20
20
20
Hose Mercedes-Benz
Mercedes-Benz Description: Breather line to fuel filter. Fuel filter / vent line.
MSRP $14.00
$10.21
MSRP $14.00
$10.21
22
Hose Clamp Mercedes-Benz
Mercedes-Benz Description: FUEL TANK TO HOSE. 9 MM - 9.5 MMInside diameter: 9,5mmOutside diameter: 11mmMaterial thickness: 0,6mm. BREATHER LINE TO ACTIVATED CHARCOAL FILTER. 9 MM - 9.5 MMInside diameter: 9,5mmOutside diameter: 11mmMaterial thickness: 0,6mm. FUEL PUMP TO TANK. 9 MM - ...
MSRP $2.50
$1.85
MSRP $2.50
$1.85
22
Binder Mercedes-Benz
Mercedes-Benz Description: Fastening to fuel filter. 10.5-13.0 mm. Fuel hose to fuel filter. 10.5-13.0 mm. Hose to intake manifold. 10.5-13.0 mm. Vacuum line to intake manifold. 10.5-13.0 mm.
MSRP $11.00
$8.12
MSRP $11.00
$8.12
25
Fuel Hose Mercedes-Benz
Mercedes-Benz Description: Fuel distributor to feed line. From fuel distributor to feed pump.
MSRP $117.00
$84.00
MSRP $117.00
$84.00
35
Hose Mercedes-Benz
Mercedes-Benz Notes: ORDER BY THE METER
Description: 160 mm. 13.3x3 mm. From fuel filter to feed line. 13.3x3 mm. 300 mm. 13.3x3 mm. 110mm. 13.3x3 mm. Order by the meter. 13.3x3 mm. 250 mm. 13.3x3 mm. From activated charcoal filter to regeneration valve. 13.3x3 mm. 100 mm from fuel return line to fuel tark. 13.3x3 mm.
MSRP $32.50
$23.99
MSRP $32.50
$23.99
40
45
Spring Hose Clamp Mercedes-Benz
Mercedes-Benz Description: Between combination valve and breather pipe. Regeneration valve. Return hose to return line. From fuel tank to breather valve.
MSRP $4.00
$2.95
MSRP $4.00
$2.95
50
Tensioner Mercedes-Benz
Mercedes-Benz Description: Underbody left. Fuel line to floor,right. To mount fuel lines. In wheelhouse front left. To firewall and longitudinal member. Brake line to cross member.
MSRP $5.00
$3.69
MSRP $5.00
$3.69
55
Holder Mercedes-Benz
Mercedes-Benz Description: Activated charcoal filter. Windshield washer pipe line to right side member. Aeration/ventilation. Regeneration line. Line to cross member. Fuel line to partition panel. On damper strut dome bracket,right. Pipe line to right wheel arch.
MSRP $6.50
$4.67
MSRP $6.50
$4.67
55
Clamp Mercedes-Benz
Mercedes-Benz Description: Activated charcoal filter. Line to cross member. Breather line to wheel arch 8 / 3,2 x 12 mm. De-aeration line 8 / 3,2 x 13 mm. Regeneration line. From return line to fuel tank.
75
Clamp Mercedes-Benz
Mercedes-Benz Description: To firewall and longitudinal member. Fuel line to floor,right. Brake and fuel lines to vehicle floor.
MSRP $2.00
$1.48
MSRP $2.00
$1.48
80
Rubber Guide Mercedes-Benz
Mercedes-Benz Notes: ORDER BY THE METER
Description: 40 mm. Lines to fire wall,top left 20 mm. Fuel lines. Lines to frame 20 mm. Feed and return lines to fire wall reinforcement 20 mm.
85
Damping Strip Mercedes-Benz
Mercedes-Benz Description: Breather line under steering. Fuel and brake lines to engine cross member. Fuel & brake lines to left side member.
90
Clamp Mercedes-Benz
Mercedes-Benz Description: Brake line mounting. Fuel lines to side member. Fuel/brake/breather lines under rear seat backrest. Brake line to side member. Mounting pipe line.
MSRP $6.50
$4.67
MSRP $6.50
$4.67
95
Damping Strip Mercedes-Benz
Mercedes-Benz Description: Fuel lines. To firewall and longitudinal member. Line mounting.
107
Rubber Bushing Mercedes-Benz
Mercedes-Benz Description: Brake line to rear seat floor right. Ant-chafe protection to longitudinal member. Line to side member. Line aux.heater right rear seat floor.
110
Clamp Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: Fuel lines. Regeneration line. At floor,rear.
122
MSRP $3.40
$2.46
125
Retaining Ring Mercedes-Benz
Mercedes-Benz Description: Rear antinoise capsule. Door pocket area. Door trim mounting left. Left basic carrier mount. Designo. Fuel line to partition panel. Damping mat to noise capsule. Step plate. Noise encapsulation.
