Steering Gear and Steering Linkage for 2005 Mercedes-Benz S430
No.
Part # / Description / Price
Price
5
Steering
Mercedes-Benz
Mercedes-Benz Notes: PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Rack-and-pinion steering.
16
MSRP $115.00
$82.80
16
MSRP $129.00
$92.40
20
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: M14X1.5
Diameter: 14mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 21mm. Tie rod to steering arm. Energy-absorbing unit to plate. Cross strut to shackle. Outside left. Track rod left. Mounting and clamp to energy-absorbing unit.
Diameter: 14mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 21mm. Tie rod to steering arm. Energy-absorbing unit to plate. Cross strut to shackle. Outside left. Track rod left. Mounting and clamp to energy-absorbing unit.
30
Clamping Piece Mercedes-Benz
Mercedes-Benz Description: Inner left and right. 68 MM. Boot to steering. 68 MM. Left and right inside. 68 mm.
MSRP $4.20
$3.08
MSRP $4.20
$3.08
35
Spring Hose Clamp Mercedes-Benz
Mercedes-Benz Description: Outer left and right. 15.2-18.5 MM. Exterior. 15.2-18.5 MM. Boot to steering. 15.2-18.5 MM. Left and right outside. 15.2-18.5 mm.
MSRP $3.20
$2.34
MSRP $3.20
$2.34
40
MSRP $9.00
$6.64
45
MSRP $6.50
$4.80
55
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Steering gear housing. D = 31.5 mm. Steering box. Line to steering.
MSRP $3.40
$2.46
MSRP $3.40
$2.46
57
MSRP $59.00
$42.00
59
MSRP $3.00
$2.21
61
Shielding Mercedes-Benz
Mercedes-Benz Description: To steering gear. Frame-type integral support,left. Rack-and-pinion steering.
63
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Bracket to c-pillar. Additional pump m6x10. Bracket to support m 6x10. Front axle brake hose. Hook to side panel m 6x10. At steering gear m6 x 10. Horn to bracket m6x10. On upper frame cross member. Charge plunger unit.
MSRP $2.50
$1.85
MSRP $2.50
$1.85
65
Nut For Tapping Screw Mercedes-Benz
Mercedes-Benz Description: Intermediate lever to pivot bearing. M14x1.5. Tie rod to steering knuckle. Joint to steering knuckle left. Left control arm. Lower control arm. Joint to wishbone m14 x 1,5. Transverse control arm. Spring control arm to wheel bearing.
75
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Rack-and-pinion steering to integral carrier. M10X75
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Steering to cross member.
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1mm. Steering to cross member.
MSRP $37.50
$27.68
MSRP $37.50
$27.68
80
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description:
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 16mm.
Diameter: 10mm
Strength / hardness class: 10.9
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 16mm.
MSRP $3.50
$2.58
MSRP $3.50
$2.58
105
Screw Mercedes-Benz
Mercedes-Benz Description: Steering coupling to steering gear. M8x39. Steering joint to steering gear and to steering shaft. Steering coupling to steering shaft and to steering. Lower steering shaft to upper steering shaft. Steering coupling to steering shaft m8 x 40. Screw universal joint. Steering coupling to steering shaft m8 x 39.
200
Repair Kit, Valve Mercedes-Benz
Mercedes-Benz Description: (repair kit). Proportioning valve. Steering gear.
MSRP $362.00
$247.38
MSRP $362.00
$247.38
210
Repair Kit, Steering Gear Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: For long oil line, with o-rings.
210
Repair Kit, Steering Gear Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: For short oil line, with o-rings.
210
220
MSRP $22.00
$15.99
1 This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.
