Battery, Starter/Alternator Cable for 2003 Mercedes-Benz S55 AMG
No.
Part # / Description / Price
Price
10
Battery 2
Mercedes-Benz
Mercedes-Benz Description: Maintenance free. 12V/92AHVolt: 12VAmps: 92AHGefahrgutkennzeichen: 9.2 Miscellaneous dangerous goods (other dangerous substances). 95 amp. In trunk. 12V/92AHVolt: 12VAmps: 92AHGefahrgutkennzeichen: 9.2 Miscellaneous dangerous goods (other dangerous substan ...
Not For Sale
Not For Sale
10
Electrical System Battery 2 Mercedes-Benz
Mercedes-Benz Description: In engine compartment. 12V/60AH
Volt: 12V
Amps: 60AH
Gefahrgutkennzeichen: 9.2 Miscellaneous dangerous goods (other dangerous substances). REAR. 12V/60AH
Volt: 12V
Amps: 60AH
Gefahrgutkennzeichen: 9.2 Miscellaneous dangerous goods (other dangerous substances).
Volt: 12V
Amps: 60AH
Gefahrgutkennzeichen: 9.2 Miscellaneous dangerous goods (other dangerous substances). REAR. 12V/60AH
Volt: 12V
Amps: 60AH
Gefahrgutkennzeichen: 9.2 Miscellaneous dangerous goods (other dangerous substances).
Not For Sale
Not For Sale
30
Protective Cap Mercedes-Benz
Mercedes-Benz Description: Positive pole. Terminal post cap. Pole cover cap. Pole, starter and on-board ele. Sys. Battery.
MSRP $4.50
$3.32
MSRP $4.50
$3.32
40
Grommet Mercedes-Benz
Mercedes-Benz Description: Acid collecting pan. 6x8 mm. Rear battery. 6X8 MM. Battery vent. 6X8 MM.
MSRP $2.00
$1.48
MSRP $2.00
$1.48
50
Angle Piece Mercedes-Benz
Mercedes-Benz Description: On battery,laterally. To side battery. Battery venting. Battery vent, on side of battery. To support battery. Elbow fitting, bleed line, battery.
MSRP $4.50
$3.32
MSRP $4.50
$3.32
70
Vent Hose Mercedes-Benz
Mercedes-Benz Notes: ORDER BY THE METER
Description: At angle. 5 x 1 mm. Support battery battery vent. 5 X 1 MM. To side battery. 5 X 1 MM. Lower edge guard in rear. 5 x 1 mm. Vent hose, buffer battery. 5 X 1 MM. Bleed line, battery. 5 X 1 MM. Battery vent, backup battery. 5 x 1 mm.
MSRP $10.00
$7.38
MSRP $10.00
$7.38
110
Pos.Cable Mercedes-Benz
Mercedes-Benz Notes: ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. A368543
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A368544
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A368544
Description: Battery b+.
120
MSRP $179.00
$121.98
140
Ground Line Mercedes-Benz
Mercedes-Benz Notes: ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. A368543
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A368544
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A368544
Description: Vehicle power supply. 180 mm. Battery to ground. 180 mm. From battery to grounf connection. 180 mm.
MSRP $58.00
$41.40
MSRP $58.00
$41.40
190
MSRP $4.00
$2.95
210
Nut Mercedes-Benz
Mercedes-Benz Description: Spring strut to body. M8
Diameter: 8mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 17,9mm
Width across flats: 13mm. Suspension strut to body. Torsion bar on body.
Diameter: 8mm
Strength / hardness class: 8
Thread code letter: M
Thread pitch: 1,25mm
Outside diameter: 17,9mm
Width across flats: 13mm. Suspension strut to body. Torsion bar on body.
260
Rail Mercedes-Benz
Mercedes-Benz Description: Battery in luggage compartement, lateral right. Battery to battery frame.
MSRP $67.00
$48.00
MSRP $67.00
$48.00
310
Fuse Box Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. Dual, left l1/6-7. Fuse box left (f1). Plug position: l1/l10 k40/2.
320
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. L3. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: SPTRelease tool: W000 589 13 99 30. Copper. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PI ...
MSRP $3.90
$2.83
MSRP $3.90
$2.83
350
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Rear rpm sensor connector x62/1. MQS. 0.5 MM2 MQS SN
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
Leitungsquerschnitt Min/Max: 0,5mm2
Oberflächenschutz PINs: Sn
Model 1: MQS
Model 2: SN
Release tool: W220 589 01 99 60
Crimp tool: W220 589 01 99 85.
MSRP $9.50
$7.01
MSRP $9.50
$7.01
2 This part contains hazardous materials. Extra shipping costs apply.
