Electric Seat Adjustment and Heated Seats; Rear for 2002 Mercedes-Benz S 55 AMG®
No.
Part # / Description / Price
Price
20
Wiring Harness
Mercedes-Benz
Mercedes-Benz Notes: ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. A368543
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A368544
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A368544
Description: Seat control module supply.
40
Spring Retaining Pin Mercedes-Benz
Mercedes-Benz Description: 1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
MSRP $3.90
$2.83
MSRP $3.90
$2.83
40
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. L3. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: SnELA: -Model 1: SPTRelease tool: W000 589 13 99 30. Copper. 0.5-1.0 MM2 SPTLeitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PI ...
MSRP $3.90
$2.83
MSRP $3.90
$2.83
60
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
MSRP $7.00
$5.17
MSRP $7.00
$5.17
70
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Fuse and relay module, driver k40/2. Fuse and relay module, front passenger k40/4. FUSE AND RELAY BOX,DRIVER. 1.0-2.5 MM2 SPT
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
Leitungsquerschnitt Min/Max: 1,0-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: SPT
Release tool: W000 589 13 99 30.
MSRP $4.90
$3.57
MSRP $4.90
$3.57
80
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. A368543
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A368544
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A368544
Description: Rear seat adjustment, air conditioned.
80
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: ORDER OBJECT NUMBER WITHOUT ES1 UP TO IDENT. NO. A368543
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A368544
ORDER OBJECT NUMBER WITH ES1 98 AS OF IDENT. NO. A368544
Description: Electric rear seat adjustment. With seat heating.
100
Receptacle Housing Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Seat adjustment control unit (n32/1,n32/2). 6-pin, cod. B. Seat heating control unit rear,natural. 6-pin, cod.
110
Receptacle Housing Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Seat heating control unit rear,blue. 6-pin, cod. C. Electric seat adjuster. 6-pin, cod.
120
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Seat heating control unit rear,grey. 6-pin, cod. D. Electric seat adjuster. 6-pin, cod.
130
Receptacle Housing Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Seat heating control unit rear,violet. 6-pin. Plug connection cigar lighter x13. 6-pin.
140
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Seat heating control unit rear,green. 6-pin. Electric seat adjuster. 6-pin.
150
Receptacle Housing Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Seat heating control unit rear,brown. 6-pin.
170
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
MSRP $3.50
$2.58
MSRP $3.50
$2.58
180
Plug Mercedes-Benz
Mercedes-Benz Description: Height adjustment motor TO A 220 545 96 28. 4-PIN JPT, MT3. Motor side flap rear shelf 4-pin m49/1. 4-pin jpt, mt3. Belt feeder,left a 10. 4-pin jpt, mt3. Fore-and-aft adjustment m27/1. M28/1. 4-pin jpt, mt3. Seat height adjustment,rear m27/2, m28/2. 4-pin jpt, mt3. Driver fore/aft seat adjustment motor m27/1. 4-pin jpt, mt3. Seat adjuster plug-connection x54. 4-pin jpt, mt3.
MSRP $6.50
$4.80
MSRP $6.50
$4.80
190
Spring Retaining Pin Mercedes-Benz
Mercedes-Benz Description: 0.5mm. 0.2-0.5 MM2 MT3
Leitungsquerschnitt Min/Max: 0,2-0,5mm2
Oberflächenschutz PINs: Au
ELA: -
Model 1: MT
Model 2: 3
Release tool: W220 589 01 99 54
Crimp tool: W220 589 04 99 32.
Leitungsquerschnitt Min/Max: 0,2-0,5mm2
Oberflächenschutz PINs: Au
ELA: -
Model 1: MT
Model 2: 3
Release tool: W220 589 01 99 54
Crimp tool: W220 589 04 99 32.
MSRP $3.00
$2.21
MSRP $3.00
$2.21
230
Contact Support Mercedes-Benz
Mercedes-Benz Description: "sam" control unit rear. 14-pin mqs
model 1: mqs
slots: 14. Light rotary switch. 14-pin mqs
model 1: mqs
slots: 14. Drive unit control unit n145*1. 14-pin mqs
model 1: mqs
slots: 14. Control unit multi-contour backrest. 14-pin mqs
model 1: mqs
slots: 14. Control unit, electronic ignition lock. 14-pin mqs
model 1: mqs
slots: 14.
model 1: mqs
slots: 14. Light rotary switch. 14-pin mqs
model 1: mqs
slots: 14. Drive unit control unit n145*1. 14-pin mqs
model 1: mqs
slots: 14. Control unit multi-contour backrest. 14-pin mqs
model 1: mqs
slots: 14. Control unit, electronic ignition lock. 14-pin mqs
model 1: mqs
slots: 14.
MSRP $3.70
$2.71
MSRP $3.70
$2.71
240
Housing Mercedes-Benz
Mercedes-Benz Description: Light rotary switch to2085450840. To 208 545 08 40.
MSRP $4.40
$3.20
MSRP $4.40
$3.20
250
MSRP $4.20
$3.08
270
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Seat heating plug-connection x54/23,x54/24. 4-pin dfk3. Contact rail seat heating 4-pol.. 4-pin dfk3. Heating pad,4-pole. 4-pin dfk3.
280
Crimp Tml Socket Contact Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 1.5-2.5 MM2 DFK3
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DFK
Model 2: 3. 1,5-2,5 MM2. 1.5-2.5 MM2 DFK3
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DFK
Model 2: 3.
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DFK
Model 2: 3. 1,5-2,5 MM2. 1.5-2.5 MM2 DFK3
Leitungsquerschnitt Min/Max: 1,5-2,5mm2
Oberflächenschutz PINs: Sn
ELA: -
Model 1: DFK
Model 2: 3.
MSRP $3.00
$2.21
MSRP $3.00
$2.21
