Front Springs and Suspension with, or Less, Adaptive Damping System for 1992 Mercedes-Benz 300SD
No.
Part # / Description / Price
Price
5
Front Spring
Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
140.028 19
140.032 19
140.033 19 580,581 AIR CONDITIONER 8
140.042 36 420,425 AUTOMATIC TRANSMISSION 4
140.043 37 228 ADDITIONAL HEATER 3
140.050 36 223 ELEKTRIC REAR SEAT ADJUSTMENT 3
140.051 38 412,414 SLIDING ROOF 3
140.056 79 471 ACCELERATION SKID CONTROL (ASR) 2
140.057 80 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1
140.134 44 274,325 AUTOTELEPHONE 1
441 STEERING COLUMN ELECTRICALLY ADJUSJABLE 1
772 1
682 FIRE EXTINGUISHER 1
440 TEMPOMAT (CRUISE CONTROL) 1
241,242 ELECTICALLY ADJUSTED FRONT SAET 1
600 HEADLAMP WIPER/WASHER 1
810 SOUND SYSTEM 1
750-759 RADIO 1
==============================================================================================================================
CHART OF FRONT SPRING RUBBER PADS
==============================================================================================================================
TOTAL OF POINTS FRONT SPRING PAD PAD
FRONT SPRING BLUE FRONT SPRING RED
SUSPENSION SUSPENSION
-21 140 321 01 04 140 321 06 84 140 321 07 84
22-28 140 321 01 04 140 321 07 84 140 321 08 84
29-35 140 321 01 04 140 321 08 84 140 321 09 84
.
36-42 140 321 02 04 140 321 06 84 140 321 07 84
43-50 140 321 02 04 140 321 07 84 140 321 08 84
51-57 140 321 02 04 140 321 08 84 140 321 09 84
.
58-65 140 321 03 04 140 321 06 84 140 321 07 84
66-73 140 321 03 04 140 321 07 84 140 321 08 84
74-80 140 321 03 04 140 321 08 84 140 321 09 84
.
81-88 140 321 04 04 140 321 06 84 140 321 07 84
89-96 140 321 04 04 140 321 07 84 140 321 08 84
96- 140 321 04 04 140 321 08 84 140 321 09 84
==============================================================================================================================
5
Front Axle Spring Mercedes-Benz
Mercedes-Benz Notes: As of ident. no.: A 120932
TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
140.028 30
140.032 33 581 AIR CONDITIONER 8
140.033 34 PARTITION PANEL 6
140.042 46 420,423,425 AUTOMATIC TRANSMISSION 4
140.043 45 228 ADDITIONAL HEATER 3
140.050 45 223 ELEKTRIC REAR SEAT ADJUSTMENT 3
140.051 48 217 ADAPTIVE DAMPING SYSTEM (ADS) 3
140.056 84 673 HIGH CAPACITY BATTERY 2
140.057 85 412,414 SLIDING ROOF 2
140.134 39 471 ACCELERATION SKID CONTROL (ASR) 1
480 SELF-LEVELLING DEVICE 1
211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1
682 FIRE EXTINGUISHER 1
481 UNDERSHIELD (STEEL PLATE) 1
440 TEMPOMAT (CRUISE CONTROL) 1
241,242 ELECTICALLY ADJUSTED FRONT SAET 1
600 HEADLAMP WIPER/WASHER 1
810 SOUND SYSTEM 1
750-759 RADIO 1
==============================================================================================================================
TABLE FRONT SPRING - RUBBER BOOT
==============================================================================================================================
SUM OF POINTS FRONT SPRING BOOT BOOT:
NORMAL SPRINGS FIRM-RIDE SPRINGS WITH BLUE FRONT SPRING W/ RED FRONT SPRING
CODE 482
-45 -27 140 321 06 04 140 321 06 84 140 321 07 84
46-52 28-34 140 321 06 04 140 321 07 84 140 321 08 84
53-59 35-41 140 321 06 04 140 321 08 84 140 321 09 84
.
60-67 42-48 140 321 07 04 140 321 06 84 140 321 07 84
68-74 49-55 140 321 07 04 140 321 07 84 140 321 08 84
75-81 56-62 140 321 07 04 140 321 08 84 140 321 09 84
.
82-90 63-70 140 321 08 04 140 321 06 84 140 321 07 84
91-97 71-78 140 321 08 04 140 321 07 84 140 321 08 84
98-105 79-85 140 321 08 04 140 321 08 84 140 321 09 84
.
106-113 86-93 140 321 09 04 140 321 06 84 140 321 07 84
114-120 94-100 140 321 09 04 140 321 07 84 140 321 08 84
121- 101- 140 321 09 04 140 321 08 84 140 321 09 84
==============================================================================================================================
As of ident. no.: A 120932 TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 140.032 AUS 54 217 ADAPTIVE DAMPING SYSTEM (ADS) 3 140.042 AUS 62 223 REAR SEAT BENCH ADJUSTMENT,ELECTRIC 3 140.043 AUS 61 471 ACCELERATION SKID CONTROL (ASR) 1 140.051 AUS 63 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1 140.057 AUS 86 481 UNDERSHIELD (STEEL PLATE) 1 . ============================================================================================================================== TABLE FRONT SPRING - RUBBER BOOT ============================================================================================================================== TOTAL OF POINTS FRONT SPRING BOOT BOOT: NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING -59 140 321 06 04 140 321 08 84 140 321 09 84 . 60-67 140 321 07 04 140 321 06 84 140 321 07 84 68-74 140 321 07 04 140 321 07 84 140 321 08 84 75-81 140 321 07 04 140 321 08 84 140 321 09 84 . 82-90 140 321 08 04 140 321 06 84 140 321 07 84 91- 140 321 08 04 140 321 07 84 140 321 08 84 ==============================================================================================================================
As of ident. no.: A 120932 TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 140.032 AUS 54 217 ADAPTIVE DAMPING SYSTEM (ADS) 3 140.042 AUS 62 223 REAR SEAT BENCH ADJUSTMENT,ELECTRIC 3 140.043 AUS 61 471 ACCELERATION SKID CONTROL (ASR) 1 140.051 AUS 63 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1 140.057 AUS 86 481 UNDERSHIELD (STEEL PLATE) 1 . ============================================================================================================================== TABLE FRONT SPRING - RUBBER BOOT ============================================================================================================================== TOTAL OF POINTS FRONT SPRING BOOT BOOT: NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING -59 140 321 06 04 140 321 08 84 140 321 09 84 . 60-67 140 321 07 04 140 321 06 84 140 321 07 84 68-74 140 321 07 04 140 321 07 84 140 321 08 84 75-81 140 321 07 04 140 321 08 84 140 321 09 84 . 82-90 140 321 08 04 140 321 06 84 140 321 07 84 91- 140 321 08 04 140 321 07 84 140 321 08 84 ==============================================================================================================================
Description: As required.
5
Front Spring Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
140.028 19
140.032 19
140.033 19 580,581 AIR CONDITIONER 8
140.042 36 420,425 AUTOMATIC TRANSMISSION 4
140.043 37 228 ADDITIONAL HEATER 3
140.050 36 223 ELEKTRIC REAR SEAT ADJUSTMENT 3
140.051 38 412,414 SLIDING ROOF 3
140.056 79 471 ACCELERATION SKID CONTROL (ASR) 2
140.057 80 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1
140.134 44 274,325 AUTOTELEPHONE 1
441 STEERING COLUMN ELECTRICALLY ADJUSJABLE 1
772 1
682 FIRE EXTINGUISHER 1
440 TEMPOMAT (CRUISE CONTROL) 1
241,242 ELECTICALLY ADJUSTED FRONT SAET 1
600 HEADLAMP WIPER/WASHER 1
810 SOUND SYSTEM 1
750-759 RADIO 1
==============================================================================================================================
CHART OF FRONT SPRING RUBBER PADS
==============================================================================================================================
TOTAL OF POINTS FRONT SPRING PAD PAD
FRONT SPRING BLUE FRONT SPRING RED
SUSPENSION SUSPENSION
-21 140 321 01 04 140 321 06 84 140 321 07 84
22-28 140 321 01 04 140 321 07 84 140 321 08 84
29-35 140 321 01 04 140 321 08 84 140 321 09 84
.
36-42 140 321 02 04 140 321 06 84 140 321 07 84
43-50 140 321 02 04 140 321 07 84 140 321 08 84
51-57 140 321 02 04 140 321 08 84 140 321 09 84
.
58-65 140 321 03 04 140 321 06 84 140 321 07 84
66-73 140 321 03 04 140 321 07 84 140 321 08 84
74-80 140 321 03 04 140 321 08 84 140 321 09 84
.
81-88 140 321 04 04 140 321 06 84 140 321 07 84
89-96 140 321 04 04 140 321 07 84 140 321 08 84
96- 140 321 04 04 140 321 08 84 140 321 09 84
==============================================================================================================================
5
Front Spring Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
140.028 19
140.032 19
140.033 19 580,581 AIR CONDITIONER 8
140.042 36 420,425 AUTOMATIC TRANSMISSION 4
140.043 37 228 ADDITIONAL HEATER 3
140.050 36 223 ELEKTRIC REAR SEAT ADJUSTMENT 3
140.051 38 412,414 SLIDING ROOF 3
140.056 79 471 ACCELERATION SKID CONTROL (ASR) 2
140.057 80 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1
140.134 44 274,325 AUTOTELEPHONE 1
441 STEERING COLUMN ELECTRICALLY ADJUSJABLE 1
772 1
682 FIRE EXTINGUISHER 1
440 TEMPOMAT (CRUISE CONTROL) 1
241,242 ELECTICALLY ADJUSTED FRONT SAET 1
600 HEADLAMP WIPER/WASHER 1
810 SOUND SYSTEM 1
750-759 RADIO 1
==============================================================================================================================
CHART OF FRONT SPRING RUBBER PADS
==============================================================================================================================
TOTAL OF POINTS FRONT SPRING PAD PAD
FRONT SPRING BLUE FRONT SPRING RED
SUSPENSION SUSPENSION
-21 140 321 01 04 140 321 06 84 140 321 07 84
22-28 140 321 01 04 140 321 07 84 140 321 08 84
29-35 140 321 01 04 140 321 08 84 140 321 09 84
.
36-42 140 321 02 04 140 321 06 84 140 321 07 84
43-50 140 321 02 04 140 321 07 84 140 321 08 84
51-57 140 321 02 04 140 321 08 84 140 321 09 84
.
58-65 140 321 03 04 140 321 06 84 140 321 07 84
66-73 140 321 03 04 140 321 07 84 140 321 08 84
74-80 140 321 03 04 140 321 08 84 140 321 09 84
.
81-88 140 321 04 04 140 321 06 84 140 321 07 84
89-96 140 321 04 04 140 321 07 84 140 321 08 84
96- 140 321 04 04 140 321 08 84 140 321 09 84
==============================================================================================================================
5
Front Axle Spring Mercedes-Benz
Mercedes-Benz Notes: As of ident. no.: A 120932
TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
140.028 30
140.032 33 581 AIR CONDITIONER 8
140.033 34 PARTITION PANEL 6
140.042 46 420,423,425 AUTOMATIC TRANSMISSION 4
140.043 45 228 ADDITIONAL HEATER 3
140.050 45 223 ELEKTRIC REAR SEAT ADJUSTMENT 3
140.051 48 217 ADAPTIVE DAMPING SYSTEM (ADS) 3
140.056 84 673 HIGH CAPACITY BATTERY 2
140.057 85 412,414 SLIDING ROOF 2
140.134 39 471 ACCELERATION SKID CONTROL (ASR) 1
480 SELF-LEVELLING DEVICE 1
211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1
682 FIRE EXTINGUISHER 1
481 UNDERSHIELD (STEEL PLATE) 1
440 TEMPOMAT (CRUISE CONTROL) 1
241,242 ELECTICALLY ADJUSTED FRONT SAET 1
600 HEADLAMP WIPER/WASHER 1
810 SOUND SYSTEM 1
750-759 RADIO 1
==============================================================================================================================
TABLE FRONT SPRING - RUBBER BOOT
==============================================================================================================================
SUM OF POINTS FRONT SPRING BOOT BOOT:
NORMAL SPRINGS FIRM-RIDE SPRINGS WITH BLUE FRONT SPRING W/ RED FRONT SPRING
CODE 482
-45 -27 140 321 06 04 140 321 06 84 140 321 07 84
46-52 28-34 140 321 06 04 140 321 07 84 140 321 08 84
53-59 35-41 140 321 06 04 140 321 08 84 140 321 09 84
.
60-67 42-48 140 321 07 04 140 321 06 84 140 321 07 84
68-74 49-55 140 321 07 04 140 321 07 84 140 321 08 84
75-81 56-62 140 321 07 04 140 321 08 84 140 321 09 84
.
82-90 63-70 140 321 08 04 140 321 06 84 140 321 07 84
91-97 71-78 140 321 08 04 140 321 07 84 140 321 08 84
98-105 79-85 140 321 08 04 140 321 08 84 140 321 09 84
.
106-113 86-93 140 321 09 04 140 321 06 84 140 321 07 84
114-120 94-100 140 321 09 04 140 321 07 84 140 321 08 84
121- 101- 140 321 09 04 140 321 08 84 140 321 09 84
==============================================================================================================================
As of ident. no.: A 120932 TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 140.032 AUS 54 217 ADAPTIVE DAMPING SYSTEM (ADS) 3 140.042 AUS 62 223 REAR SEAT BENCH ADJUSTMENT,ELECTRIC 3 140.043 AUS 61 471 ACCELERATION SKID CONTROL (ASR) 1 140.051 AUS 63 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1 140.057 AUS 86 481 UNDERSHIELD (STEEL PLATE) 1 . ============================================================================================================================== TABLE FRONT SPRING - RUBBER BOOT ============================================================================================================================== TOTAL OF POINTS FRONT SPRING BOOT BOOT: NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING -59 140 321 06 04 140 321 08 84 140 321 09 84 . 60-67 140 321 07 04 140 321 06 84 140 321 07 84 68-74 140 321 07 04 140 321 07 84 140 321 08 84 75-81 140 321 07 04 140 321 08 84 140 321 09 84 . 82-90 140 321 08 04 140 321 06 84 140 321 07 84 91- 140 321 08 04 140 321 07 84 140 321 08 84 ==============================================================================================================================
As of ident. no.: A 120932 TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 140.032 AUS 54 217 ADAPTIVE DAMPING SYSTEM (ADS) 3 140.042 AUS 62 223 REAR SEAT BENCH ADJUSTMENT,ELECTRIC 3 140.043 AUS 61 471 ACCELERATION SKID CONTROL (ASR) 1 140.051 AUS 63 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1 140.057 AUS 86 481 UNDERSHIELD (STEEL PLATE) 1 . ============================================================================================================================== TABLE FRONT SPRING - RUBBER BOOT ============================================================================================================================== TOTAL OF POINTS FRONT SPRING BOOT BOOT: NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING -59 140 321 06 04 140 321 08 84 140 321 09 84 . 60-67 140 321 07 04 140 321 06 84 140 321 07 84 68-74 140 321 07 04 140 321 07 84 140 321 08 84 75-81 140 321 07 04 140 321 08 84 140 321 09 84 . 82-90 140 321 08 04 140 321 06 84 140 321 07 84 91- 140 321 08 04 140 321 07 84 140 321 08 84 ==============================================================================================================================
Description: As required.
5
MSRP $135.00
$97.20
5
Front Spring Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
140.028 30
140.032 33 581 AIR CONDITIONER 8
140.033 34 PARTITION PANEL 6
140.042 46 420,423,425 AUTOMATIC TRANSMISSION 4
140.043 45 228 ADDITIONAL HEATER 3
140.050 45 223 ELEKTRIC REAR SEAT ADJUSTMENT 3
140.051 48 217 ADAPTIVE DAMPING SYSTEM (ADS) 3
140.056 84 673 HIGH CAPACITY BATTERY 2
140.057 85 412,414 SLIDING ROOF 2
140.134 50 471 ACCELERATION SKID CONTROL (ASR) 1
140.135 51 480 SELF-LEVELLING DEVICE 1
211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1
682 FIRE EXTINGUISHER 1
481 UNDERSHIELD (STEEL PLATE) 1
440 TEMPOMAT (CRUISE CONTROL) 1
241,242 ELECTICALLY ADJUSTED FRONT SAET 1
600 HEADLAMP WIPER/WASHER 1
810 SOUND SYSTEM 1
750-759 RADIO 1
==============================================================================================================================
TABLE FRONT SPRING - RUBBER BOOT
==============================================================================================================================
TOTAL OF POINTS FRONT SPRING BOOT BOOT:
NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING
-32 140 321 20 04 140 321 06 84 140 321 07 84
33-38 140 321 20 04 140 321 07 84 140 321 08 84
39-44 140 321 20 04 140 321 08 84 140 321 09 84
.
45-50 140 321 24 04 140 321 06 84 140 321 07 84
51-56 140 321 24 04 140 321 07 84 140 321 08 84
57-61 140 321 24 04 140 321 08 84 140 321 09 84
.
62-67 140 321 25 04 140 321 06 84 140 321 07 84
68-74 140 321 25 04 140 321 07 84 140 321 08 84
75-80 140 321 25 04 140 321 08 84 140 321 09 84
.
81-86 140 321 23 04 140 321 06 84 140 321 07 84
87-92 140 321 23 04 140 321 07 84 140 321 08 84
93- 140 321 23 04 140 321 08 84 140 321 09 84
==============================================================================================================================
CHART OF FRONT SPRING RUBBER PADS CODE 482
==============================================================================================================================
TOTAL OF POINTS FRONT SPRING PAD PAD
H.D.SPRING FRONT SPRING BLUE FRONT SPRING RED
SUSPENSION SUSPENSION
CODE 482
-36 140 321 24 04 140 321 06 84 140 321 07 84
37-42 140 321 24 04 140 321 07 84 140 321 08 84
43-48 140 321 24 04 140 321 07 84 140 321 08 84
.
49-53 140 321 25 04 140 321 06 84 140 321 07 84
54-59 140 321 25 04 140 321 07 84 140 321 08 84
60-65 140 321 25 04 140 321 08 84 140 321 09 84
.
66-71 140 321 23 04 140 321 06 84 140 321 07 84
72-77 140 321 23 04 140 321 07 84 140 321 08 84
78-83 140 321 23 04 140 321 08 84 140 321 09 84
.
84-88 140 321 09 04 140 321 06 84 140 321 07 84
89-96 140 321 09 04 140 321 07 84 140 321 08 84
97- 140 321 09 04 140 321 08 84 140 321 09 84
==============================================================================================================================
TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 140.032 AUS 54 217 ADAPTIVE DAMPING SYSTEM (ADS) 3 140.042 AUS 62 223 REAR SEAT BENCH ADJUSTMENT,ELECTRIC 3 140.043 AUS 61 471 ACCELERATION SKID CONTROL (ASR) 1 140.051 AUS 63 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1 140.057 AUS 86 481 UNDERSHIELD (STEEL PLATE) 1 600 HEADLAMP WIPER/WASHER 1 ============================================================================================================================== TABLE FRONT SPRING - RUBBER BOOT ============================================================================================================================== TOTAL OF POINTS FRONT SPRING BOOT BOOT: NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING -56 140 321 24 04 140 321 07 84 140 321 08 84 57-61 140 321 24 04 140 321 08 84 140 321 09 84 . 62-67 140 321 25 04 140 321 00684 140 321 07 84 68-74 140 321 25 04 140 321 07 84 140 321 08 84 75-80 140 321 25 04 140 321 08 84 140 321 09 84 . 81-86 140 321 23 04 140 321 06 84 140 321 07 84 87- 140 321 23 04 140 321 07 84 140 321 08 84 ==============================================================================================================================
TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 140.032 AUS 54 217 ADAPTIVE DAMPING SYSTEM (ADS) 3 140.042 AUS 62 223 REAR SEAT BENCH ADJUSTMENT,ELECTRIC 3 140.043 AUS 61 471 ACCELERATION SKID CONTROL (ASR) 1 140.051 AUS 63 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1 140.057 AUS 86 481 UNDERSHIELD (STEEL PLATE) 1 600 HEADLAMP WIPER/WASHER 1 ============================================================================================================================== TABLE FRONT SPRING - RUBBER BOOT ============================================================================================================================== TOTAL OF POINTS FRONT SPRING BOOT BOOT: NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING -56 140 321 24 04 140 321 07 84 140 321 08 84 57-61 140 321 24 04 140 321 08 84 140 321 09 84 . 62-67 140 321 25 04 140 321 00684 140 321 07 84 68-74 140 321 25 04 140 321 07 84 140 321 08 84 75-80 140 321 25 04 140 321 08 84 140 321 09 84 . 81-86 140 321 23 04 140 321 06 84 140 321 07 84 87- 140 321 23 04 140 321 07 84 140 321 08 84 ==============================================================================================================================
Description: As required.
MSRP $177.00
$120.84
MSRP $177.00
$120.84
5
Front Axle Spring Mercedes-Benz
Mercedes-Benz Notes: As of ident. no.: A 120932
TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
140.028 30
140.032 33 581 AIR CONDITIONER 8
140.033 34 PARTITION PANEL 6
140.042 46 420,423,425 AUTOMATIC TRANSMISSION 4
140.043 45 228 ADDITIONAL HEATER 3
140.050 45 223 ELEKTRIC REAR SEAT ADJUSTMENT 3
140.051 48 217 ADAPTIVE DAMPING SYSTEM (ADS) 3
140.056 84 673 HIGH CAPACITY BATTERY 2
140.057 85 412,414 SLIDING ROOF 2
140.134 39 471 ACCELERATION SKID CONTROL (ASR) 1
480 SELF-LEVELLING DEVICE 1
211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1
682 FIRE EXTINGUISHER 1
481 UNDERSHIELD (STEEL PLATE) 1
440 TEMPOMAT (CRUISE CONTROL) 1
241,242 ELECTICALLY ADJUSTED FRONT SAET 1
600 HEADLAMP WIPER/WASHER 1
810 SOUND SYSTEM 1
750-759 RADIO 1
==============================================================================================================================
TABLE FRONT SPRING - RUBBER BOOT
==============================================================================================================================
SUM OF POINTS FRONT SPRING BOOT BOOT:
NORMAL SPRINGS FIRM-RIDE SPRINGS WITH BLUE FRONT SPRING W/ RED FRONT SPRING
CODE 482
-45 -27 140 321 06 04 140 321 06 84 140 321 07 84
46-52 28-34 140 321 06 04 140 321 07 84 140 321 08 84
53-59 35-41 140 321 06 04 140 321 08 84 140 321 09 84
.
60-67 42-48 140 321 07 04 140 321 06 84 140 321 07 84
68-74 49-55 140 321 07 04 140 321 07 84 140 321 08 84
75-81 56-62 140 321 07 04 140 321 08 84 140 321 09 84
.
82-90 63-70 140 321 08 04 140 321 06 84 140 321 07 84
91-97 71-78 140 321 08 04 140 321 07 84 140 321 08 84
98-105 79-85 140 321 08 04 140 321 08 84 140 321 09 84
.
106-113 86-93 140 321 09 04 140 321 06 84 140 321 07 84
114-120 94-100 140 321 09 04 140 321 07 84 140 321 08 84
121- 101- 140 321 09 04 140 321 08 84 140 321 09 84
==============================================================================================================================
As of ident. no.: A 120932 TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 140.032 AUS 54 217 ADAPTIVE DAMPING SYSTEM (ADS) 3 140.042 AUS 62 223 REAR SEAT BENCH ADJUSTMENT,ELECTRIC 3 140.043 AUS 61 471 ACCELERATION SKID CONTROL (ASR) 1 140.051 AUS 63 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1 140.057 AUS 86 481 UNDERSHIELD (STEEL PLATE) 1 . ============================================================================================================================== TABLE FRONT SPRING - RUBBER BOOT ============================================================================================================================== TOTAL OF POINTS FRONT SPRING BOOT BOOT: NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING -59 140 321 06 04 140 321 08 84 140 321 09 84 . 60-67 140 321 07 04 140 321 06 84 140 321 07 84 68-74 140 321 07 04 140 321 07 84 140 321 08 84 75-81 140 321 07 04 140 321 08 84 140 321 09 84 . 82-90 140 321 08 04 140 321 06 84 140 321 07 84 91- 140 321 08 04 140 321 07 84 140 321 08 84 ==============================================================================================================================
As of ident. no.: A 120932 TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 140.032 AUS 54 217 ADAPTIVE DAMPING SYSTEM (ADS) 3 140.042 AUS 62 223 REAR SEAT BENCH ADJUSTMENT,ELECTRIC 3 140.043 AUS 61 471 ACCELERATION SKID CONTROL (ASR) 1 140.051 AUS 63 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1 140.057 AUS 86 481 UNDERSHIELD (STEEL PLATE) 1 . ============================================================================================================================== TABLE FRONT SPRING - RUBBER BOOT ============================================================================================================================== TOTAL OF POINTS FRONT SPRING BOOT BOOT: NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING -59 140 321 06 04 140 321 08 84 140 321 09 84 . 60-67 140 321 07 04 140 321 06 84 140 321 07 84 68-74 140 321 07 04 140 321 07 84 140 321 08 84 75-81 140 321 07 04 140 321 08 84 140 321 09 84 . 82-90 140 321 08 04 140 321 06 84 140 321 07 84 91- 140 321 08 04 140 321 07 84 140 321 08 84 ==============================================================================================================================
Description: As required.
MSRP $165.00
$118.80
MSRP $165.00
$118.80
5
Front Axle Spring Mercedes-Benz
Mercedes-Benz Notes: As of ident. no.: A 120932
TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
140.028 30
140.032 33 581 AIR CONDITIONER 8
140.033 34 PARTITION PANEL 6
140.042 46 420,423,425 AUTOMATIC TRANSMISSION 4
140.043 45 228 ADDITIONAL HEATER 3
140.050 45 223 ELEKTRIC REAR SEAT ADJUSTMENT 3
140.051 48 217 ADAPTIVE DAMPING SYSTEM (ADS) 3
140.056 84 673 HIGH CAPACITY BATTERY 2
140.057 85 412,414 SLIDING ROOF 2
140.134 39 471 ACCELERATION SKID CONTROL (ASR) 1
480 SELF-LEVELLING DEVICE 1
211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1
682 FIRE EXTINGUISHER 1
481 UNDERSHIELD (STEEL PLATE) 1
440 TEMPOMAT (CRUISE CONTROL) 1
241,242 ELECTICALLY ADJUSTED FRONT SAET 1
600 HEADLAMP WIPER/WASHER 1
810 SOUND SYSTEM 1
750-759 RADIO 1
==============================================================================================================================
TABLE FRONT SPRING - RUBBER BOOT
==============================================================================================================================
SUM OF POINTS FRONT SPRING BOOT BOOT:
NORMAL SPRINGS FIRM-RIDE SPRINGS WITH BLUE FRONT SPRING W/ RED FRONT SPRING
CODE 482
-45 -27 140 321 06 04 140 321 06 84 140 321 07 84
46-52 28-34 140 321 06 04 140 321 07 84 140 321 08 84
53-59 35-41 140 321 06 04 140 321 08 84 140 321 09 84
.
60-67 42-48 140 321 07 04 140 321 06 84 140 321 07 84
68-74 49-55 140 321 07 04 140 321 07 84 140 321 08 84
75-81 56-62 140 321 07 04 140 321 08 84 140 321 09 84
.
82-90 63-70 140 321 08 04 140 321 06 84 140 321 07 84
91-97 71-78 140 321 08 04 140 321 07 84 140 321 08 84
98-105 79-85 140 321 08 04 140 321 08 84 140 321 09 84
.
106-113 86-93 140 321 09 04 140 321 06 84 140 321 07 84
114-120 94-100 140 321 09 04 140 321 07 84 140 321 08 84
121- 101- 140 321 09 04 140 321 08 84 140 321 09 84
==============================================================================================================================
Description: As required.
5
Front Spring Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
140.028 19
140.032 19
140.033 19 580,581 AIR CONDITIONER 8
140.042 36 420,425 AUTOMATIC TRANSMISSION 4
140.043 37 228 ADDITIONAL HEATER 3
140.050 36 223 ELEKTRIC REAR SEAT ADJUSTMENT 3
140.051 38 412,414 SLIDING ROOF 3
140.056 79 471 ACCELERATION SKID CONTROL (ASR) 2
140.057 80 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1
140.134 44 274,325 AUTOTELEPHONE 1
441 STEERING COLUMN ELECTRICALLY ADJUSJABLE 1
772 1
682 FIRE EXTINGUISHER 1
440 TEMPOMAT (CRUISE CONTROL) 1
241,242 ELECTICALLY ADJUSTED FRONT SAET 1
600 HEADLAMP WIPER/WASHER 1
810 SOUND SYSTEM 1
750-759 RADIO 1
==============================================================================================================================
CHART OF FRONT SPRING RUBBER PADS
==============================================================================================================================
TOTAL OF POINTS FRONT SPRING PAD PAD
FRONT SPRING BLUE FRONT SPRING RED
SUSPENSION SUSPENSION
-21 140 321 01 04 140 321 06 84 140 321 07 84
22-28 140 321 01 04 140 321 07 84 140 321 08 84
29-35 140 321 01 04 140 321 08 84 140 321 09 84
.
36-42 140 321 02 04 140 321 06 84 140 321 07 84
43-50 140 321 02 04 140 321 07 84 140 321 08 84
51-57 140 321 02 04 140 321 08 84 140 321 09 84
.
58-65 140 321 03 04 140 321 06 84 140 321 07 84
66-73 140 321 03 04 140 321 07 84 140 321 08 84
74-80 140 321 03 04 140 321 08 84 140 321 09 84
.
81-88 140 321 04 04 140 321 06 84 140 321 07 84
89-96 140 321 04 04 140 321 07 84 140 321 08 84
96- 140 321 04 04 140 321 08 84 140 321 09 84
==============================================================================================================================
5
Front Axle Spring Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
140.028 30
140.032 33 581 AIR CONDITIONER 8
140.033 34 PARTITION PANEL 6
140.042 46 420,423,425 AUTOMATIC TRANSMISSION 4
140.043 45 228 ADDITIONAL HEATER 3
140.050 45 223 ELEKTRIC REAR SEAT ADJUSTMENT 3
140.051 48 217 ADAPTIVE DAMPING SYSTEM (ADS) 3
140.056 84 673 HIGH CAPACITY BATTERY 2
140.057 85 412,414 SLIDING ROOF 2
140.134 50 471 ACCELERATION SKID CONTROL (ASR) 1
140.135 51 480 SELF-LEVELLING DEVICE 1
211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1
682 FIRE EXTINGUISHER 1
481 UNDERSHIELD (STEEL PLATE) 1
440 TEMPOMAT (CRUISE CONTROL) 1
241,242 ELECTICALLY ADJUSTED FRONT SAET 1
600 HEADLAMP WIPER/WASHER 1
810 SOUND SYSTEM 1
750-759 RADIO 1
==============================================================================================================================
TABLE FRONT SPRING - RUBBER BOOT
==============================================================================================================================
TOTAL OF POINTS FRONT SPRING BOOT BOOT:
NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING
-32 140 321 20 04 140 321 06 84 140 321 07 84
33-38 140 321 20 04 140 321 07 84 140 321 08 84
39-44 140 321 20 04 140 321 08 84 140 321 09 84
.
45-50 140 321 24 04 140 321 06 84 140 321 07 84
51-56 140 321 24 04 140 321 07 84 140 321 08 84
57-61 140 321 24 04 140 321 08 84 140 321 09 84
.
62-67 140 321 25 04 140 321 06 84 140 321 07 84
68-74 140 321 25 04 140 321 07 84 140 321 08 84
75-80 140 321 25 04 140 321 08 84 140 321 09 84
.
81-86 140 321 23 04 140 321 06 84 140 321 07 84
87-92 140 321 23 04 140 321 07 84 140 321 08 84
93- 140 321 23 04 140 321 08 84 140 321 09 84
==============================================================================================================================
CHART OF FRONT SPRING RUBBER PADS CODE 482
==============================================================================================================================
TOTAL OF POINTS FRONT SPRING PAD PAD
H.D.SPRING FRONT SPRING BLUE FRONT SPRING RED
SUSPENSION SUSPENSION
CODE 482
-36 140 321 24 04 140 321 06 84 140 321 07 84
37-42 140 321 24 04 140 321 07 84 140 321 08 84
43-48 140 321 24 04 140 321 07 84 140 321 08 84
.
49-53 140 321 25 04 140 321 06 84 140 321 07 84
54-59 140 321 25 04 140 321 07 84 140 321 08 84
60-65 140 321 25 04 140 321 08 84 140 321 09 84
.
66-71 140 321 23 04 140 321 06 84 140 321 07 84
72-77 140 321 23 04 140 321 07 84 140 321 08 84
78-83 140 321 23 04 140 321 08 84 140 321 09 84
.
84-88 140 321 09 04 140 321 06 84 140 321 07 84
89-96 140 321 09 04 140 321 07 84 140 321 08 84
97- 140 321 09 04 140 321 08 84 140 321 09 84
==============================================================================================================================
TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 140.032 AUS 54 217 ADAPTIVE DAMPING SYSTEM (ADS) 3 140.042 AUS 62 223 REAR SEAT BENCH ADJUSTMENT,ELECTRIC 3 140.043 AUS 61 471 ACCELERATION SKID CONTROL (ASR) 1 140.051 AUS 63 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1 140.057 AUS 86 481 UNDERSHIELD (STEEL PLATE) 1 600 HEADLAMP WIPER/WASHER 1 ============================================================================================================================== TABLE FRONT SPRING - RUBBER BOOT ============================================================================================================================== TOTAL OF POINTS FRONT SPRING BOOT BOOT: NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING -56 140 321 24 04 140 321 07 84 140 321 08 84 57-61 140 321 24 04 140 321 08 84 140 321 09 84 . 62-67 140 321 25 04 140 321 00684 140 321 07 84 68-74 140 321 25 04 140 321 07 84 140 321 08 84 75-80 140 321 25 04 140 321 08 84 140 321 09 84 . 81-86 140 321 23 04 140 321 06 84 140 321 07 84 87- 140 321 23 04 140 321 07 84 140 321 08 84 ==============================================================================================================================
TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 140.032 AUS 54 217 ADAPTIVE DAMPING SYSTEM (ADS) 3 140.042 AUS 62 223 REAR SEAT BENCH ADJUSTMENT,ELECTRIC 3 140.043 AUS 61 471 ACCELERATION SKID CONTROL (ASR) 1 140.051 AUS 63 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1 140.057 AUS 86 481 UNDERSHIELD (STEEL PLATE) 1 600 HEADLAMP WIPER/WASHER 1 ============================================================================================================================== TABLE FRONT SPRING - RUBBER BOOT ============================================================================================================================== TOTAL OF POINTS FRONT SPRING BOOT BOOT: NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING -56 140 321 24 04 140 321 07 84 140 321 08 84 57-61 140 321 24 04 140 321 08 84 140 321 09 84 . 62-67 140 321 25 04 140 321 00684 140 321 07 84 68-74 140 321 25 04 140 321 07 84 140 321 08 84 75-80 140 321 25 04 140 321 08 84 140 321 09 84 . 81-86 140 321 23 04 140 321 06 84 140 321 07 84 87- 140 321 23 04 140 321 07 84 140 321 08 84 ==============================================================================================================================
Description: As required.
5
Front Axle Spring Mercedes-Benz
Mercedes-Benz Notes: TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND
OF THE SPECIAL VERSIONS INSTALLED
==============================================================================================================================
MODEL POINTS CODE SPECIAL EQUIPMENT POINTS
140.028 30
140.032 33 581 AIR CONDITIONER 8
140.033 34 PARTITION PANEL 6
140.042 46 420,423,425 AUTOMATIC TRANSMISSION 4
140.043 45 228 ADDITIONAL HEATER 3
140.050 45 223 ELEKTRIC REAR SEAT ADJUSTMENT 3
140.051 48 217 ADAPTIVE DAMPING SYSTEM (ADS) 3
140.056 84 673 HIGH CAPACITY BATTERY 2
140.057 85 412,414 SLIDING ROOF 2
140.134 50 471 ACCELERATION SKID CONTROL (ASR) 1
140.135 51 480 SELF-LEVELLING DEVICE 1
211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1
682 FIRE EXTINGUISHER 1
481 UNDERSHIELD (STEEL PLATE) 1
440 TEMPOMAT (CRUISE CONTROL) 1
241,242 ELECTICALLY ADJUSTED FRONT SAET 1
600 HEADLAMP WIPER/WASHER 1
810 SOUND SYSTEM 1
750-759 RADIO 1
==============================================================================================================================
TABLE FRONT SPRING - RUBBER BOOT
==============================================================================================================================
TOTAL OF POINTS FRONT SPRING BOOT BOOT:
NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING
-32 140 321 20 04 140 321 06 84 140 321 07 84
33-38 140 321 20 04 140 321 07 84 140 321 08 84
39-44 140 321 20 04 140 321 08 84 140 321 09 84
.
45-50 140 321 24 04 140 321 06 84 140 321 07 84
51-56 140 321 24 04 140 321 07 84 140 321 08 84
57-61 140 321 24 04 140 321 08 84 140 321 09 84
.
62-67 140 321 25 04 140 321 06 84 140 321 07 84
68-74 140 321 25 04 140 321 07 84 140 321 08 84
75-80 140 321 25 04 140 321 08 84 140 321 09 84
.
81-86 140 321 23 04 140 321 06 84 140 321 07 84
87-92 140 321 23 04 140 321 07 84 140 321 08 84
93- 140 321 23 04 140 321 08 84 140 321 09 84
==============================================================================================================================
CHART OF FRONT SPRING RUBBER PADS CODE 482
==============================================================================================================================
TOTAL OF POINTS FRONT SPRING PAD PAD
H.D.SPRING FRONT SPRING BLUE FRONT SPRING RED
SUSPENSION SUSPENSION
CODE 482
-36 140 321 24 04 140 321 06 84 140 321 07 84
37-42 140 321 24 04 140 321 07 84 140 321 08 84
43-48 140 321 24 04 140 321 07 84 140 321 08 84
.
49-53 140 321 25 04 140 321 06 84 140 321 07 84
54-59 140 321 25 04 140 321 07 84 140 321 08 84
60-65 140 321 25 04 140 321 08 84 140 321 09 84
.
66-71 140 321 23 04 140 321 06 84 140 321 07 84
72-77 140 321 23 04 140 321 07 84 140 321 08 84
78-83 140 321 23 04 140 321 08 84 140 321 09 84
.
84-88 140 321 09 04 140 321 06 84 140 321 07 84
89-96 140 321 09 04 140 321 07 84 140 321 08 84
97- 140 321 09 04 140 321 08 84 140 321 09 84
==============================================================================================================================
TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 140.032 AUS 54 217 ADAPTIVE DAMPING SYSTEM (ADS) 3 140.042 AUS 62 223 REAR SEAT BENCH ADJUSTMENT,ELECTRIC 3 140.043 AUS 61 471 ACCELERATION SKID CONTROL (ASR) 1 140.051 AUS 63 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1 140.057 AUS 86 481 UNDERSHIELD (STEEL PLATE) 1 600 HEADLAMP WIPER/WASHER 1 ============================================================================================================================== TABLE FRONT SPRING - RUBBER BOOT ============================================================================================================================== TOTAL OF POINTS FRONT SPRING BOOT BOOT: NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING -56 140 321 24 04 140 321 07 84 140 321 08 84 57-61 140 321 24 04 140 321 08 84 140 321 09 84 . 62-67 140 321 25 04 140 321 00684 140 321 07 84 68-74 140 321 25 04 140 321 07 84 140 321 08 84 75-80 140 321 25 04 140 321 08 84 140 321 09 84 . 81-86 140 321 23 04 140 321 06 84 140 321 07 84 87- 140 321 23 04 140 321 07 84 140 321 08 84 ==============================================================================================================================
TO ASCERTAIN THE FRONT SPRINGS,PLEASE ADD UP IN THE CHART BELOW THE NUMBERS OF POINTS OF THE RESPECTIVE MODEL AND OF THE SPECIAL VERSIONS INSTALLED ============================================================================================================================== MODEL POINTS CODE SPECIAL EQUIPMENT POINTS 140.032 AUS 54 217 ADAPTIVE DAMPING SYSTEM (ADS) 3 140.042 AUS 62 223 REAR SEAT BENCH ADJUSTMENT,ELECTRIC 3 140.043 AUS 61 471 ACCELERATION SKID CONTROL (ASR) 1 140.051 AUS 63 211 AUTOMATIC LOCKING DIFFERENTIAL (ASD)1 140.057 AUS 86 481 UNDERSHIELD (STEEL PLATE) 1 600 HEADLAMP WIPER/WASHER 1 ============================================================================================================================== TABLE FRONT SPRING - RUBBER BOOT ============================================================================================================================== TOTAL OF POINTS FRONT SPRING BOOT BOOT: NORMAL SUSPENSION WITH BLUE FRONT SPRING W/ RED FRONT SPRING -56 140 321 24 04 140 321 07 84 140 321 08 84 57-61 140 321 24 04 140 321 08 84 140 321 09 84 . 62-67 140 321 25 04 140 321 00684 140 321 07 84 68-74 140 321 25 04 140 321 07 84 140 321 08 84 75-80 140 321 25 04 140 321 08 84 140 321 09 84 . 81-86 140 321 23 04 140 321 06 84 140 321 07 84 87- 140 321 23 04 140 321 07 84 140 321 08 84 ==============================================================================================================================
Description: As required.
8
Helical Spring Shim Mercedes-Benz
Mercedes-Benz Description: As required. Number of burls: 1 (8 mm).
MSRP $16.00
$11.69
MSRP $16.00
$11.69
8
Helical Spring Shim Mercedes-Benz
Mercedes-Benz Description: As required. Number of burls: 4 (23 mm).
MSRP $17.50
$12.92
MSRP $17.50
$12.92
11
MSRP $1,170.00
$798.00
12
MSRP $1,650.00
$1,128.60
12
Shock Absorber Mercedes-Benz
Mercedes-Benz Notes: FROM IDENT NO. A 212245 ALSO INSTALLED ON A 187334 - A 212243 WITH CODE 867
Description: Range of delivery.
14
Nut Mercedes-Benz
Mercedes-Benz Notes: IMPORTANT: OBSERVE CHANGED TIGHTENING TORQUES
Description: Hydropneumatic spring leg to spring control arm. Shock absorber to lower control arm. Shock absorber to spring control arm.
14
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: M10
Diameter: 10mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 16mm. Rod to torsion bar. Shock absorber to frame. Trailer coupling to bracket. Camber struts to wheel bearing m 10. Shock absorber to spring control arm m 10. Axle housing to rear subframe. Tie rod to wheel bearing m10.
Diameter: 10mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 16mm. Rod to torsion bar. Shock absorber to frame. Trailer coupling to bracket. Camber struts to wheel bearing m 10. Shock absorber to spring control arm m 10. Axle housing to rear subframe. Tie rod to wheel bearing m10.
MSRP $3.90
$2.83
MSRP $3.90
$2.83
17
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: SHOCK ABSORBER TO LOWER CONTROL ARMDiameter: 12mmStrength / hardness class: 10.9Thread code letter: MThread pitch: 1,5mm. Trailing arm to mounting consoleDiameter: 12mmStrength / hardness class: 10.9Thread code letter: MThread pitch: 1,5mm. Left trailing a ...
MSRP $37.00
$27.06
MSRP $37.00
$27.06
20
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: Spring control arm to rear subframe. Upper transverse control arm to steering knuckle. Lower control arm to steering knuckle. Torsion bar to frame. Lower joint to control arm. Joint to steering knuckle. Shock absorber to lower control arm.
MSRP $7.50
$5.54
MSRP $7.50
$5.54
